Builds a forest plot highlighting the most extreme positive and negative DELTA/Stouffer statistics within a chosen rank. The plot shows the top n_pos_each features on the positive side and the top n_neg_each features on the negative side, ordered by the selected statistic (statistic_to_plot). This provides a compact summary of which features shift most strongly between the two groups for a given rank.

Usage

forestplot(
  results_tbl,
  rank_of_interest,
  statistic_to_plot = c("T", "T_stand", "Z_from_p"),
  n_neg_each = 15,
  n_pos_each = 15,
  filter_significant = "none",
  sig_level = 0.05,
  left_label = "More in group1",
  right_label = "More in group2",
  arrow_length_frac = 0.35,
  label_x_gap_frac = 0.06,
  y_pad = 0.6,
  label_y_offset = 0,
  label_vjust = -0.3,
  arrow_color = "red",
  arrow_linewidth = 0.6,
  arrow_head_length_mm = 3,
  use_diverging_colors = FALSE,
  base_text_pt = 12,
  font_family = "Montserrat",
  seg_width = 1.2,
  point_size = 3.6,
  show_grid = FALSE
)

Arguments

results_tbl

Data frame/tibble with at least: rank, feature, group1, group2, design, T_obs, p_perm.

rank_of_interest

Character scalar specifying the rank to plot (e.g., "species").

statistic_to_plot

Which statistic to rank/plot: "T" (raw T_obs), "T_stand" (permutation-standardized), or "Z_from_p" (signed Z from permutation p).

n_neg_each

Number of most negative features to show. Default 15.

n_pos_each

Number of most positive features to show. Default 15.

filter_significant

Column name to filter on, or "none" to disable filtering. If the column is numeric, keep rows where col <= sig_level.

sig_level

Significance threshold used when filter_significant is numeric. Default 0.05.

left_label

Text for the left arrow/side label.

right_label

Text for the right arrow/side label.

arrow_length_frac

Fraction of max \(|T|\) used as half-length of arrows.

label_x_gap_frac

Horizontal gap for arrow labels beyond arrow tips (fraction of max \(|T|\)).

y_pad

Vertical padding above the top category for arrows/labels (y-axis units).

label_y_offset

Additional vertical offset for arrow-end labels (y-axis units).

label_vjust

Vertical justification for arrow labels (passed to annotate()).

arrow_color

Arrow/label color.

arrow_linewidth

Arrow line width.

arrow_head_length_mm

Arrow head length in mm.

use_diverging_colors

Logical; if TRUE, lines/points are shaded blue (negative) to red (positive) with higher contrast; otherwise monochrome.

base_text_pt

Base text size in points for the plot.

font_family

Font family for plot text.

seg_width

Segment line width for the horizontal bars.

point_size

Point size for feature markers.

show_grid

Logical; show major/minor grid lines.

Value

A list with:

  • data - tibble used for plotting (selected top/bottom items),

  • plot - ggplot object.

Details

The y-axis lists feature names (sorted by the chosen statistic), and the x-axis shows the signed effect size for each feature. Each feature is drawn as a horizontal segment from zero to its statistic value, with a point at the end of the segment. A dashed vertical line marks zero to separate negative from positive shifts. The subtitle reports the contrast (group1 vs group2) and how many negative/positive features are shown.

If use_diverging_colors = TRUE, segments/points are colored by magnitude on a blue-to-red scale (negative to positive), otherwise a single color is used. The arrow annotations at the top label the direction of enrichment for each group and help interpret the sign of the statistic.

statistic_to_plot controls the statistic used for both ranking and plotting: raw T_obs, permutation-standardized T_obs_stand, or Z_from_p (signed Z from permutation p-values). For calibrated inference or cross-figure comparability, prefer permutation Z-based results or T_stand.

Examples


# in this example we mock the output of compute_delta with a simple
# data.frame - it works the same
set.seed(1)
n <- 20
results_tbl <- data.frame(
  rank = rep("species", n),
  feature = paste0("feat_", seq_len(n)),
  group1 = "control",
  group2 = "treated",
  design = "case-control",
  T_obs = rnorm(n, sd = 2),
  p_perm = runif(n),
  T_obs_stand = rnorm(n),
  Z_from_p = qnorm(1 - runif(n) / 2) * sign(rnorm(n))
)

out <- forestplot(
  results_tbl,
  rank_of_interest = "species",
  statistic_to_plot = "T",
  n_neg_each = 5,
  n_pos_each = 5,
  left_label = "More in control",
  right_label = "More in treated",
  use_diverging_colors = TRUE,
  font_family = "sans"
)

print(out$plot)
